Automated Skull Diploe Thickness Mapping

Advanced morphological tracking and segmentation of skull layers utilizing native ITK thickness filters.

Understanding variations in skull thickness, particularly resolving the complex diploe internal spongy bone layer, requires delicate segmentation. This project aimed to create a fully computational thickness map over the entire skull using programmatic control within Slicer, allowing high-throughput calculations across patient cohorts.

3D rendering of patient's skull showing continuous diploe thickness mapping. Blue areas indicate thinner bone regions while red indicates significantly thicker regions. Bottom panel displays structured automated measurements for different bone zones.

Technical Approach

The Python script fully encapsulates the complex multi-step pipeline inside Slicer. To ensure that only true skull regions were selected, automated operations parsed multiple algorithms sequentially:

  • Automated Thresholding: Instantiated a class-based pipeline to programmatically connect volume nodes and invoke segment editor operations (Thresholding using specific bone density scales).
  • Morphological Healing: Utilized kernel-based operations—KEEP_LARGEST_ISLAND and MORPHOLOGICAL_CLOSING—to remove artifacts, patch holes seamlessly, and construct the outer skull constraint shell.
  • Constraint-based Boolean Operations: Cloned segmentations, altered mask modes, and utilized logical overlap settings to calculate the internal diploe boundaries.
  • Advanced ITK Filtering: Pulled VTK volumes to SimpleITK to execute complex computational geometry. First, BinaryThinningImageFilter resolved the medial axis of the bone segment. Second, DanielssonDistanceMapImageFilter calculated the exact mathematical thickness mapping onto the object.
  • Data Export: Final scene reconstructions generated dynamic models containing quantitative arrays, which then systematically batch exported VTK models and color tables mapped for all folder inputs.
A precise 2D cross-sectional view of the segmentation logic executing on the image array. The gold outer skull delineates the physical boundary, while the inner light blue segment algorithmically tracks the diploe bone tissue properties.

Technologies Used

  • 3D Slicer 5.x
  • Python Scripting
  • SimpleITK & vtkITK APIs
  • VTK Object Modeling
